Manage grid card authenticators

Grid authentication uses cards with a grid as the authentication lookup tool. When asked to authenticate with a grid, the challenge presents the user with coordinates, for example, B3, H1. The user references the challenge coordinates on their grid card and responds by typing the corresponding values.

Typically, your organization creates grid cards, distributes them to users, and then assigns the grid card serial numbers to users. Users can have multiple grid cards assigned to them and they can also self-register their grid cards in the User Portal.

note

An IDaaS account can have a maximum of 5000 unassigned grid cards.

Example

A grid card is similar to the one shown in this example. Using this grid card as an example, the correct response to a grid challenge of B3, H1 is E 5.

Prerequisites

• You must have a role with User Grid Card Management permissions to manage grid cards.
• Configure grid as an authentication option for IDaaS (see Create and manage resource rules).
• Customize the Grid Card authenticator settings, as required.
• Create and assign grid cards to users.

Grid card state

IDaaS supports the following grid card states:

State	Description	Authentication use	Notes
ACTIVE	The grid card has been used at least one time. The last used date of the imported card is set to the current date.	Yes	—
INACTIVE	The grid card cannot be used at this time.	No	—
UNASSIGNED	The grid card has not been assigned to a user.	No	—
PENDING	The grid card can be used for authentication. After the first successful authentication, the state changes to ACTIVE.	Yes	Default state if not specified
CANCELED	The grid card can no longer be used and counts toward the maximum number of grid cards a user can have.	No	Can be deleted; cannot return to another state; cannot be unassigned

note

The State column is not case-sensitive. For example, Active, active, and ACTIVE are recognized.

Migrating Entrust Identity grid cards to IDaaS

To migrate Entrust Identity grid cards to IDaaS, use the instructions in the Entrust Identity Enterprise to IDaaS Migration Guide available on Entrust Trusted Care. Once logged in to Trusted Care, do the following:

1. Click Products.
2. On the My Products page navigate to Identity Enterprise > Identity to IDaaS Migration Tool.
3. On the Identity Enterprise to IDaaS Migration Tool page, click Documents.
4. Click Download next to Migration Guide: Entrust Identity to IDaaS.

The Entrust Identity Migration operation converts the grid card state as follow:

Entrust Identity State	IDaaS State
CURRENT	ACTIVE
HOLD	INACTIVE
HOLD PENDING	INACTIVE
PENDING	PENDING
CANCELED	CANCELED
